New

Intel NUC 11 NUC11PHKI7 Enthusiast Kit

Manufacturer: Intel

Reference RNUC11PHKI7C002

Condition: New

More info

Intel® Optane™ Memory Supported Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.Intel® Virtualization Technology for Directed I/O (VT-d) Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.Intel® HD Audio Technology Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.Intel® Rapid Storage Technology Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.Intel® Platform Trust Technology (Intel® PTT) Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.

Built-in processor	Y
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	11th gen Intel® Core™ i7
Processor model	i7-1165G7
Processor cores	4
Processor threads	8
Processor boost frequency	4.7 GHz
Processor cache	12 MB
CPU configuration (max)	1
Memory slots type	SO-DIMM
Number of memory slots	2
Maximum internal memory	64 GB
Supported memory clock speeds	3200 MHz
Supported memory types	DDR4-SDRAM
Memory bandwidth (max)	51.2 GB/s
Memory voltage	1.2 V
Non-ECC	Y
Supported storage drive types	SSD
Storage drive sizes supported	M.2
SSD form factor	M.2
Storage drive interface	M.2, Serial ATA III
Number of storage drives supported	2
Card reader integrated	Y
Compatible memory cards	SDXC
On-board graphics card	Y
Graphics card family	Intel
On-board graphics card model	Intel Iris Xe Graphics
Discrete graphics card model	NVIDIA® GeForce RTX™ 2060
Built-in speaker(s)	N
Ethernet LAN	Y
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
LAN controller	Intel I225-LM
Bluetooth	Y
Bluetooth version	5.2
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
HDMI version	2.0a
Mini DisplayPorts quantity	1
DisplayPort version	1.4
Combo headphone/mic port	Y
S/PDIF out port	Y
Number of SATA III connectors	1
Product colour	Black
Cooling type	Active
Product type	Mini PC
On/off switch	Y
ARK ID	202783
Trusted Platform Module (TPM)	N
Audio output channels	7.1 channels
Windows operating systems supported	Windows 10
Intel® vPro™ Platform Eligibility	N
Intel® High Definition Audio (Intel® HD Audio)	Y
Embedded options available	N
Intel Rapid Storage Technology	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Idle States	Y
Intel Trusted Execution Technology	N
Intel Stable Image Platform Program (SIPP)	N
Intel® Optane™ Memory Ready	Y
Intel® Platform Trust Technology (Intel® PTT)	Y
Intel Virtualization Technology (VT-x)	Y
Harmonized System (HS) code	84713000
Power supply type	External AC adapter
Power supply	150 W
Display included	N
