| Cable length | 0.25 m |
| Cable standard | Cat6a |
| Cable shielding | F/FTP (FFTP) |
| Connector 1 | RJ-45 |
| Connector 2 | RJ-45 |
| Product colour | Red |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Connector contacts plating | Gold |
| Connector shielding | Y |
| Jacket material | Low smoke zero halogen (LSZH) |
| Cable shape | Flat |
| Conductor type | Stranded |
| Conductor material | Copper |
| Cabling technology | 10GBase-T |
| Ethernet interface type | 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.5 |
| AWG wire size | 32/7 |
| Data transfer rate | 10000 Mbit/s |
| Frequency | 500 MHz |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) type supported | PoE+ |
| Molded cable boot | Y |
| Plug and Play | Y |
| Country of origin | China |
| Width | 8.34 mm |
| Depth | 11.7 mm |
| Height | 250 mm |
| Outer diameter | 3.8 mm |
| Weight | 16 g |
| Quantity per pack | 1 pc(s) |
| Package width | 140 mm |
| Package depth | 10 mm |
| Package height | 180 mm |
| Package type | Polybag |
| Sustainability compliance | Y |
| Sustainability certificates | CE, REACH, RoHS |
| Doesn't contain | Halogen |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 380 mm |
| Master (outer) case length | 290 mm |
| Master (outer) case gross weight | 5.6 kg |
| Master (outer) case height | 350 mm |
| Products per master (outer) case | 600 pc(s) |
