LINDY 4 Port HDMI 8K60 Splitter mit Audio

Reference 38535

Condition: New

More info

The Lindy 4 Port HDMI® 8K60 Splitter with Audio is a multi-function solution for distributing high quality HDMI® signals across 2 displays simultaneously from one source device, while extracting digital or analogue audio separately.

With support for resolutions up to 8K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching dual display digital signage in retail scenarios, displaying live video across two screens at event venues or distributing engaging multiscreen educational presentations at tradeshows.

The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI® to connect non-HDMI® amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.

The splitters also features an integrated switch to downscale the input signal to 4K or Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.

The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Video ports quantity	4
Video port type	HDMI
Video out	4x HDMI
HDMI version	2.1
Digital audio optical out	1
Headphone out	Jā
Headphone connectivity	3.5 mm
DC-in jack	Jā
Maximum resolution	7680 x 4320 pixels
Product colour	Black
Housing material	Metal
HD type	8K Ultra HD
Colour depth	8 bit
Maximum refresh rate	60 Hz
HDCP version	2.3
Data transfer rate	48 Gbit/s
HDCP	Jā
Easy to install	Jā
LED indicators	Jā
Certification	CE, FCC, RoHS, REACH & California Proposition 65
AC input voltage	5 V
Input current	2 A
Width	176 mm
Depth	17 mm
Height	68 mm
Weight	375 g
Quantity per pack	1 pc(s)
Package width	240 mm
Package depth	70 mm
Package height	130 mm
Package weight	510 g
Package type	Box
Manual	Jā
Cables included	Power
AC adapter included	Jā
Included power plug types	AU, EU, UK
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	20 - 90%
Connector 1	4 x HDMI Type A
Connector 2	HDMI Type A
Warranty period	2 year(s)
Compliance certificates	CE, Federal Communications Commission (FCC), REACH, RoHS
