New

Intel Core i7 13700 LGA1700 30MB Cache 3,4GHz retail

Manufacturer: Intel

Reference BX8071513700

Condition: New

More info

Intel® Gaussian & Neural Accelerator Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.Intel® Deep Learning Boost (Intel® DL Boost) A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.Intel® Turbo Boost Technology Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.Intel® Turbo Boost Max Technology 3.0 Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Processor family	Intel® Core™ i7
Processor cores	16
Processor socket	LGA 1700
Box	Y
Processor manufacturer	Intel
Processor model	i7-13700
Processor operating modes	64-bit
Processor generation	13th gen Intel® Core™ i7
Processor threads	24
Performance cores	8
Efficient cores	8
Processor boost frequency	5.2 GHz
Performance-core boost frequency	5.1 GHz
Performance-core base frequency	2.1 GHz
Efficient-core boost frequency	4.1 GHz
Efficient-core base frequency	1.5 GHz
Processor cache	30 MB
Processor cache type	Smart Cache
Processor base power	65 W
Maximum turbo power	219 W
Bus type	DMI4
Maximum number of DMI lanes	8
Memory bandwidth supported by processor (max)	89.6 GB/s
Processor codename	Raptor Lake
Processor ARK ID	230490
Memory channels	Dual-channel
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
ECC	Y
Memory bandwidth (max)	89.6 GB/s
On-board graphics card	Y
Discrete graphics card	N
On-board graphics card model	Intel UHD Graphics 770
Discrete graphics card model	Not available
On-board graphics card outputs supported	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1600 MHz
Number of displays supported (on-board graphics)	4
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card ID	0xA780
Number of execution units	32
Multi-Format Codec Engines	2
Execute Disable Bit	Y
Idle States	Y
Thermal Monitoring Technologies	Y
Market segment	Desktop
Use conditions	PC/Client/Tablet, Workstation
Maximum number of PCI Express lanes	20
PCI Express slots version	5.0, 4.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
CPU configuration (max)	1
Embedded options available	Y
Direct Media Interface (DMI) Revision	4.0
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Intel® Hyper Threading Technology (Intel® HT Technology)	Y
Intel® Turbo Boost Technology	2.0
Intel® Quick Sync Video Technology	Y
Intel® Clear Video HD Technology (Intel® CVT HD)	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Enhanced Intel SpeedStep Technology	Y
Intel Trusted Execution Technology	Y
Intel® Speed Shift Technology	Y
Intel® Turbo Boost Max Technology 3.0 frequency	5.2 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Y
Intel® Control-flow Enforcement Technology (CET)	Y
Intel® Thread Director	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Intel® Secure Key	Y
Intel® Active Management Technology (Intel® AMT)	Y
Intel Stable Image Platform Program (SIPP)	Y
Intel® OS Guard	Y
Intel 64	Y
Intel Virtualization Technology (VT-x)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel Turbo Boost Max Technology 3.0	Y
Intel® Boot Guard	Y
Intel® Deep Learning Boost (Intel® DL Boost)	Y
Intel® Volume Management Device (VMD)	Y
Mode-based Execute Control (MBE)	Y
Intel® vPro™ Platform Eligibility	Y
Intel® Standard Manageability (ISM)	Y
Intel® One-Click Recovery	Y
Intel® Remote Platform Erase (RPE)	Y
Intel® Virtualization Technology with Redirect Protection (VT-rp)	Y
Intel vPro® Enterprise Platform Eligibility	Y
Intel® Threat Detection Technology (TDT)	Y
Intel® Hardware Shield Eligibility	Y
Intel® Total Memory Encryption - Multi Key	Y
Intel vPro® Essentials Platform Eligibility	Y
Tjunction	100 °C
OpenCL version	3.0
Harmonized System (HS) code	8542310001
Package type	Retail box
Processor package size	45 x 37.5 mm
L2 cache	24576 KB
Maximum internal memory	128 GB
Target market	Gaming, Content Creation
Launch date	Q1'23
Status	Launched
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1
