New

Intel Core i9 13900F LGA1700 36MB Cache 2,0GHz retail

Manufacturer: Intel

Reference BX8071513900F

Condition: New

More info

Intel® Gaussian & Neural Accelerator Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.Intel® Deep Learning Boost (Intel® DL Boost) A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.Intel® Speed Shift Technology Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.Intel® Thermal Velocity Boost Intel® Thermal Velocity Boost (Intel® TVB) is a feature that opportunistically and automatically increases clock frequency above single-core and multi-core Intel® Turbo Boost Technology frequencies based on how much the processor is operating below its maximum temperature and whether turbo power budget is available. The frequency gain and duration is dependent on the workload, capabilities of the processor and the processor cooling solution.Intel® Turbo Boost Max Technology 3.0 Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.Intel® Hyper-Threading Technology Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.Idle States Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.Enhanced Intel SpeedStep® Technology Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Processor family	Intel® Core™ i9
Processor cores	24
Processor socket	LGA 1700
Box	Y
Processor manufacturer	Intel
Processor model	i9-13900F
Processor operating modes	64-bit
Processor generation	13th gen Intel® Core™ i9
Processor threads	32
Performance cores	8
Efficient cores	16
Processor boost frequency	5.6 GHz
Performance-core boost frequency	5.2 GHz
Performance-core base frequency	2 GHz
Efficient-core boost frequency	4.2 GHz
Efficient-core base frequency	1.5 GHz
Processor cache	36 MB
Processor cache type	Smart Cache
Processor base power	65 W
Maximum turbo power	219 W
Bus type	DMI4
Maximum number of DMI lanes	8
Memory bandwidth supported by processor (max)	89.6 GB/s
Processor codename	Raptor Lake
Processor ARK ID	230502
Memory channels	Dual-channel
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth (max)	89.6 GB/s
On-board graphics card	N
Discrete graphics card	N
On-board graphics card model	Not available
Discrete graphics card model	Not available
Execute Disable Bit	Y
Idle States	Y
Thermal Monitoring Technologies	Y
Market segment	Desktop
Use conditions	PC/Client/Tablet
Maximum number of PCI Express lanes	20
PCI Express slots version	5.0, 4.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
CPU configuration (max)	1
Embedded options available	N
Direct Media Interface (DMI) Revision	4.0
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Intel® Hyper Threading Technology (Intel® HT Technology)	Y
Intel® Turbo Boost Technology	2.0
Intel® AES New Instructions (Intel® AES-NI)	Y
Enhanced Intel SpeedStep Technology	Y
Intel® Speed Shift Technology	Y
Intel® Thermal Velocity Boost	Y
Intel® Adaptive Boost Technology	Y
Intel® Turbo Boost Max Technology 3.0 frequency	5.5 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Y
Intel® Thermal Velocity Boost Frequency	5.6 GHz
Intel® Control-flow Enforcement Technology (CET)	Y
Intel® Thread Director	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Intel® Secure Key	Y
Intel® OS Guard	Y
Intel 64	Y
Intel Virtualization Technology (VT-x)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel Turbo Boost Max Technology 3.0	Y
Intel® Boot Guard	Y
Intel® Deep Learning Boost (Intel® DL Boost)	Y
Intel® Volume Management Device (VMD)	Y
Mode-based Execute Control (MBE)	Y
Intel® Standard Manageability (ISM)	Y
Tjunction	100 °C
Harmonized System (HS) code	8542310001
Package type	Retail box
Processor package size	45 x 37.5 mm
L2 cache	32768 KB
Maximum internal memory	128 GB
Target market	Gaming, Content Creation
Launch date	Q1'23
Status	Launched
