Agile traffic control for converged networking applicationsZyXEL XGS2210/GS2210 Series has a rich Layer 2 feature set that can shape the traffic for diverse VoIP, video conference, IPTV and IP surveillance deployments and provide hotels, businesses andeducational institutions greater agility and more effective traffic management for the converged applications of today.ZyXEL One Network experienceAiming for relieving our customers from repetitive operations of deploying and managing a network, ZyXEL One Network is designed to simplify the configuration, management, and troubleshooting, allowing our customers to focus on the business priorities. ZyXEL One Network presents an easy-to-use tool, ZyXEL One Network Utility (ZON Utility), to realize speed network setup. ZyXEL Smart Connect allows ZyXEL networking equipment to be aware and recognize each other and further facilitating the network maintenance via one-click remote functions such as factory reset or power cycling. ZyXEL One Network redefines the network integration across multiple networking products from switch to Wi-Fi AP and to Gateway.High-powered Power over Ethernet (PoE)The ZyXEL XGS2210/GS2210 Series PoE switches support the IEEE 802.3af PoE and 802.3at PoE Plus standards, which provide up to 30 watts of power per port for advanced Powered Devices (PD) like 802.11ac wireless APs and video IP phones. The high power budget enables the XGS2210/GS2210 PoE switches to comfortably accommodate the PDs required in a modern network edge.High-powered Power over Ethernet (PoE)The ZyXEL XGS2210/GS2210 Series PoE switches support the IEEE 802.3af PoE and 802.3at PoE Plus standards, which provide up to 30 watts of power per port for advanced Powered Devices (PD) like 802.11ac wireless APs and video IP phones. The high power budget enables the XGS2210/GS2210 PoE switches to comfortably accommodate the PDs required in a modern network edge.
|
| Switch type | Managed | | Switch layer | L2 | | Quality of Service (QoS) support | Y | | Web-based management | Y | | Traffic shaping | Y | | ARP inspection | Y | | System event log | Y | | MIB support | RFC 1066, RFC 1213, RFC 1493, RFC 1643, RFC 1757, RFC 2011, RFC 2233, RFC 2358, RFC 2674, RFC 2819, RFC 2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293 | | Basic switching RJ-45 Ethernet ports quantity | 48 | | Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) | | SFP+ module slots quantity | 4 | | Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | | 10G support | Y | | Port mirroring | Y | | IP routing | Y | | Flow control support | Y | | Link aggregation | Y | | Broadcast storm control | Y | | Rate limiting | Y | | Spanning tree protocol | Y | | MAC address auto-learning supported | Y | | VLAN support | Y | | Virtual LAN features | Private VLAN, Protocol-based VLAN, Port-based VLAN | | MAC address table | 16000 entries | | Switching capacity | 176 Gbit/s | | Throughput | 130.9 Mpps | | Number of queues | 8 | | Jumbo frames support | Y | | Jumbo frames | 9000 | | Packet buffer memory | 1.5 MB | | DHCP features | DHCP client | | Access Control List (ACL) | Y | | IGMP snooping | Y | | Security algorithms | 802.1x RADIUS, SNMP, SSH, SSH-2 | | MAC address filtering | Y | | SSH/SSL support | Y | | BPDU filtering/protection | Y | | Authentication | MAC-based authentication | | Multicast support | Y | | Rack mounting | Y | | Stackable | Y | | Form factor | 1U | | Product colour | Black | | Safety | LVD, BSMI | | Electromagnetic compatibility | FCC 15 (A), CE (A), BSMI | | Certification | RoHS | | Noise level | 44.15 dB | | Plug and Play | Y | | Mean time between failures (MTBF) | 970594 h | | AC input voltage | 100 - 240 V | | AC input frequency | 50 - 60 Hz | | Power consumption (max) | 45 W | | Power over Ethernet (PoE) | N | | Operating temperature (T-T) | 0 - 50 °C | | Storage temperature (T-T) | -40 - 70 °C | | Operating relative humidity (H-H) | 10 - 95% | | Storage relative humidity (H-H) | 10 - 90% | | Heat dissipation | 153.3 BTU/h | | Width | 441 mm | | Depth | 270 mm | | Height | 45 mm | | Weight | 3.86 kg | | Cables included | AC | | Rack mount kit | Y | | Package width | 622 mm | | Package depth | 358 mm | | Package height | 108 mm | | Package weight | 4.92 kg | | Harmonized System (HS) code | 85176990 |
|
