Zyxel Smart Switch 8x GbE GS1900-8HP V3 L2 PoE 70Watt

ZYXEL

GS1900-8HP-EU0103F

New

Simple, Fast and Smart Managed Switches for Small Business ConnectivityThe ZyXEL GS1900 Series of 8/10/16/24/48-port GbE Smart Managed Switch with Gigabit speed and essential managing functions bring your business network more flexibility and connectivity. The 1900 Series consists of nine (9) models—the GS1900-8, GS1900-8HP, GS1900-10HP, GS1900- 16, GS1900-24E, GS1900-24, GS1900-24HP, GS1900-48 and GS1900-48HP. Providing GbE switches with power-saving functions, fanless design and full IPv6 support ensure your network to be ready for future expansions. In addition, the PoE models GS1900-8HP/10HP/24HP/48HP Gigabit switch complies with the IEEE 802.3at Power over Ethernet (PoE) Plus standard. The complete GS1900 Series has been designed with useful features and advanced performances that empower your networks with speed and security as well as silent operation in your office environments.The complete ZyXEL GS1900 Series has an essential portfolio of 8/10/16/24/48-port compact desktop and rackmount size with GbE connectivity. All models support multiple deployment methods to fulfill the needs for small offices and meeting room environments such as wall-, under table- or desktop-mounting and rackmount options1. It’s now quick and effortless to enjoy the high-speed business network applications without a hitch. Additionally, the GS1900-10HP/24/24HP/48/48HP is equipped with 2 extra SFP slots to provide 100M and GbE speeds for long-distance deployments.The GS1900-8HP/10HP/24HP/48HP features IEEE 802.3at PoE Plus with up to 30 W powers per port to flexibly extend network deployment, especially for high-power devices such as Wi-Fi APs, IP cams and IP phones. The 802.3at PoE Plus capability makes the switch ideal for connecting numerous powered devices to form a flawless business network.

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportY
Web-based managementY
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power connectorDC-in jack
Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Full duplexY
Flow control supportY
Broadcast storm controlY
Rate limitingY
Auto MDI/MDI-XY
VLAN supportY
MAC address table8000 entries
Switching capacity16 Gbit/s
Number of queues8
Jumbo frames supportY
Jumbo frames9216
DHCP featuresDHCP client
IGMP snoopingY
Security algorithms802.1x RADIUS
MAC address filteringY
Multicast supportY
Product colourBlack
Reset buttonY
CertificationCE, FCC, C-Tick, RoHS
Mean time between failures (MTBF)533086 h
Power sourceAC/DC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)90 W
Power over Ethernet (PoE)Y
Power over Ethernet (PoE) ports quantity8
Total Power over Ethernet (PoE) budget70 W
Operating relative humidity (H-H)10 - 90%
Width250 mm
Depth104 mm
Height27 mm
Weight710 g
Harmonized System (HS) code85176990
