Equip HDMI UHS Ethernet 2.1 A-A St/St 20.0m 8K60Hz HDR sw

Reference 119452

Condition: New

More info

The equip 119452 is Active Optical Cables (AOC) are fiber optic cables that use electrical-to-optical conversion circuitry to transmit signals over longer distances with less signal loss and electromagnetic interference compared to traditional copper cables.

HDMI 2.1 Active Optical Cable combines the advantages of both technologies to provide high-speed, high-bandwidth, and reliable connectivity for advanced audio and video applications. These cables use fiber optic technology to transmit signals over longer distances without any signal degradation or loss.

Ideal for applications such as home theaters, conference rooms, classrooms, and digital signage installations where long-distance HDMI connectivity is required. These cables are also thinner, lighter, and more flexible than traditional copper cables, making them easier to install and manage.

By supporting a maximum bandwidth of 48 Gbps, content up to 8K Ultra HD (7680 x 4320 @ 60 Hz) resolution can be displayed.

Cable length	20 m
Connector 1	HDMI Type A (Standard)
Connector 2	HDMI Type A (Standard)
Connector 1 gender	Male
Connector 2 gender	Male
Product colour	Black
Connector contacts plating	Gold
Quantity per pack	1 pc(s)
Connector 1 form factor	Straight
Connector 2 form factor	Straight
HDMI version	2.1
3D	Y
Supported graphics resolutions	1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160, 5120 x 2880, 7680 x 4320
Audio Return Channel (ARC)	Y
HDMI Ethernet channel	Y
HDCP	Y
HDCP version	2.2
Bandwidth	48000 MB/s
High Dynamic Range (HDR) supported	Y
Maximum refresh rate	120 Hz
Extended display identification data (EDID)	Y
Weight	460 g
Package width	205 mm
Package depth	65 mm
Package height	205 mm
Package weight	650 g
Package type	Box
Country of origin	China
Sustainability compliance	Y
Sustainability certificates	CE, RoHS
Master (outer) case width	300 mm
Master (outer) case length	230 mm
Master (outer) case height	460 mm
Master (outer) case gross weight	6.5 kg
Products per master (outer) case	10 pc(s)
