ASUS ROG-STRIX-RTX4090-O24G-EVA-02-Edition 24GB GDDR6X

ASUS

90YV0ID5-M0NM00

New

ROG Strix GeForce RTX™ 4090 24GB GDDR6X OC EVA-02 Edition with DLSS 3 and chart-topping thermal performance.

ROG x EVANGELION - Designed by ROG. Tested by NERV. The Ultimate EVA.
Step into the future with the ROG Strix GeForce RTX 4090 OC EVA-02 Edition. Designed in collaboration with the EVANGELION project, this powerhouse graphics card boasts a stunning aesthetic inspired by EVA-02. The shroud and backplate feature intricate design elements, while the front ARGB panel showcases the iconic synchronization effect.

Axial-tech Upgrades
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 23% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.

Patented Vapor Chamber
A vapor chamber featuring milled pathways lets the heatpipes sink in without being pressed flat, allowing heat to be carried more efficiently to the fin stack. In comparison to conventional vapor chamber and heatpipe combos, this potent pairing reduces GPU temperature by up to 5 Celsius when subjected to a 500W thermal load.

Metal Exoskeleton
A high-quality diecast frame, shroud, and backplate tightly brace the PCB and strategically steer airflow.

Graphics processor familyNVIDIA
Graphics processorGeForce RTX 4090
Maximum resolution7680 x 4320 pixels
CUDA
Parallel processing technology supportNot supported
CUDA cores16384
Processor boost clock speed2610 MHz
Processor frequency (OC mode)2640 MHz
Maximum displays per videocard4
Discrete graphics card memory24 GB
Graphics card memory typeGDDR6X
Memory bus384 bit
Memory bandwidth (max)21 GB/s
Interface typePCI Express 4.0
HDMI ports quantity2
DisplayPorts quantity3
HDMI version2.1a
DisplayPort version1.4a
OpenGL version4.6
Dual Link DVI
HDCP
HDCP version2.3
Cooling typeActive
Cooling technologyASUS Axial-tech
Number of fans3 fan(s)
Number of slots3.5
Illumination
Illumination colourMulti
Product colourMulticolour
Minimum system power supply1000 W
Supplementary power connectors1x 16-pin
Depth70.1 mm
Height149.3 mm
Width357.6 mm
