Digitus 8-Port Multi-Gigabit Switch, 2.5G, unmanaged

Digitus

DN-80230

New

8-Port 2.5G Switch 4-Speed Multi-Gigabit Unmanaged Switch

Multi-gigabit switch with 2.5 Gbps bandwidth per port - also suitable for higher network loads in small to medium-sized networks

8 x RJ45 ports 10/100/1000/2500 Mbps (4-speed)
All ports support 2.5 Gbps bandwidth
Network standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz
Full-duplex flow control IEEE 802.3x
High backplane bandwidth of 40 Gbps
Auto-negotiation / auto MDI/MDI-X
No configuration necessary
Automatic detection of cable and network standard
Wall installation possible

The 8-Port Multi-Gigabit Switch (4-Speed) from DIGITUS® provides 8 x RJ45 ports with 2.5 Gbps bandwidth each. Expand your existing network easily with the available backplane bandwidth of 40 Gbps. No configuration is required on the switch itself; thanks to auto-negotiation and auto MDI/MDI-X, cables and speeds are also automatically detected. The switch can be used as a desktop variant or mounted on a wall with the included mounting accessories. Thanks to the external power adapter, the switch does not need a fan at all. Ideal for expanding / setting up small home or business networks with data rates of up to 2.5 Gbps - so even high workloads due to high-resolution streams or high data volumes are no problem.

Number of ports: 8
Ethernet speed: Gigabit
Industrial usage: false
Installation type: Desktop, Wall
Managed: false
Number of ports (Uplink): 0
Outdoorsuitable: false
PoE (Power over Ethernet): false
Protection against vanadlism: false
VLAN: false
Number of ports: 8 x 10/100/1000/2500 Mbps (4-speed).
Network standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz
Auto-negotiation: Auto MDI/MDI-X
IEEE 802.3x full-duplex flow control
Backplane bandwidth: 40 Gbps
Transfer method: Store and forward
Forwarding capacity: 3.7 Mpps (@2.5G)
LED displays: 10/100/1000 Mbps Link/Act, 2.5 Gbps Link/Act, Power
Jumbo frames: 12 Kb
Buffer memory: 12 Mbit
MAC addresses: 16K
Fanless design
Operating voltage: 12 V DC / 1.8 A
Power consumption: 12 W max.
Power supply, power adapter: 100 - 240 V AC, 50/60 Hz, 21.6 W
Plug type, power adapter: Euro plug Type C (CEE 7/16)
Plug type, device side: Coaxial plug (DC) 5.5 mm / 2.1 mm
Operating temperature: 0 °C to +40 °C
Operating humidity: 10% - 90% RH (non-condensing)
Storage temperature: -10 °C to +60 °C
Fanless design (air flow cooling)
Dimensions: W 190 x D 120 x H 30 mm
Weight: 735 g

Package content:
1 x 8-Port Gigabit Switch, 2.5G, Unmanaged
1 x Power adapter
1 x Accessories for wall mounting
1 x Quick start guide

Platums(cm)29.5
Grums(cm)13
Augstums(cm)6
Svars(kg)0.47
Tilpums(cm3)2301
Izcelsmes valstsHK
