| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u |
| 10G support | Nē |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Full duplex | Jā |
| Auto MDI/MDI-X | Jā |
| Auto-negotiation | Jā |
| MAC address auto-learning supported | Jā |
| MAC address auto-aging supported | Jā |
| MAC address table | 1000 entries |
| Switching capacity | 10 Gbit/s |
| Store-and-forward | Jā |
| Jumbo frames support | Jā |
| Jumbo frames | 9000 |
| Packet forwarding rate (1 Gbps) | 1488100 pps |
| Packet forwarding rate (100 Mbps) | 148810 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Stackable | Nē |
| Product colour | Black |
| LED indicators | Activity, Link, Power |
| Country of origin | China |
| Certification | CE, FCC |
| Buffer size | 64 KB |
| Input current | 0.6 A |
| Input voltage | 5 V |
| Power over Ethernet (PoE) | Nē |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 86 mm |
| Depth | 23 mm |
| Height | 89 mm |
| Weight | 71.4 g |
| Quick start guide | Jā |
| AC adapter included | Jā |
| Package type | Box |
| Package width | 95 mm |
| Package depth | 82 mm |
| Package height | 98 mm |
| Package weight | 184 g |
| Master (outer) case width | 495 mm |
| Master (outer) case length | 191 mm |
| Master (outer) case height | 516 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 10.2 kg |
| Products per master (outer) case | 50 pc(s) |
