LINDY DST-Mini Plus USB Typ C 4K HDMI Mini Dockingstation

Reference 43278

Condition: New

More info

Adds 3 USB 3.1 Gen 1 / USB 3.0 Type A ports, an HDMI and VGA port as well as a Gigabit Ethernet port to a laptop Supports 4K UHD 3840x2160@30Hz for HDMI displays and Full HD 1920x1080@60Hz for VGA displays Features DisplayPort Alternate Mode USB Power Delivery 3.0 capable up to 100W 2 year warrantyThe Lindy USB 3.1 Type C Laptop Mini Dock is a compact and multifunctional solution for connecting Laptops, tablets or smartphones to a range of interfaces including displays, all over a single Type C cable. Featuring all the interfaces needed for a modern workstation, this USB 3.1 Type C Laptop Mini Dock uses a single USB 3.1 Type C cable to simultaneously connect a laptop to a display and provide power, Gigabit Ethernet and USB 3.1 Gen 1 / USB 3.0 SuperSpeed ports. It also features a card reader for SD and microSD cards.The Mini Dock enables the connection of a display to a laptop via HDMI at resolutions of 3840x2160@30Hz or via VGA at 1920x1080@60Hz using DisplayPort Alternate Mode through the USB Type C port. If a VGA and HDMI display are connected simultaneously, this Mini Dock works as a splitter with maximum resolution of 1920x1080@60Hz for each display with the same video content.With support for USB Power Delivery up to 100W it is also able to provide power to a laptop using the Type C port. The three integrated USB 3.1 Gen 1 / USB 3.0 Type A ports provide up to 5Gbps of data transfer. Perfect for connecting Type A peripherals such as a hard drive, printer or webcam.Information about USB 3.0, 3.1 & 3.2USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface. USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps. USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.

Ports quantity	7
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Hub interfaces	HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, VGA
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
HDMI ports quantity	1
VGA (D-Sub) ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB Type-C DisplayPort Alternate Mode	Y
Card reader integrated	Y
Card reader slot	2
Compatible memory cards	MicroSD (TransFlash), SD
Data transfer rate	5000 Mbit/s
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160
Supported video modes	1080p, 2160p
Maximum resolution (HDMI)	3840 x 2160 pixels
Product colour	Grey
Housing material	Aluminium
HDCP	Y
HDCP version	2.2
USB Power Delivery	Y
USB Power Delivery revision	3.0
USB Power Delivery up to	100 W
Certification	CE, UKCA, FCC, REACH, RoHS, CP65
Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Power supply type	USB
Width	180 mm
Depth	17 mm
Height	49 mm
Weight	90 g
Quantity per pack	1 pc(s)
Package width	174 mm
Package depth	194 mm
Package weight	100 g
Package type	Polybag
Manual	Y
Maximum operating temperature	45 °C
Operating temperature (T-T)	0 - 45 °C
Operating temperature (T-T)	32 - 113 °F
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	20 - 80%
Harmonized System (HS) code	84719000
Chipset	RTL8153B, EP9632G, GL3510
