LINDY Receiver HDMI & IR über Cat6 1080p bis 100m

Lindy

38129

New

Add additional HDMI over IP receivers to create larger networked distribution setups Simple, scalable solution for developing 1-to-many or many-to-many installations Supports resolutions up to 1920x1080@60Hz 4:4: 4 8bit Supports IR extension from the transmitter 2 year warrantyIP extenders provide reliable extension of HDMI signals on a network connection, allowing for point to point and mixed configurations when combined with network equipment such as switches. Utilising IP connectivity ensures a low cost, scalable extension solution that can be easily setup for a variety of small or larger scale scenarios.The Lindy HDMI & IR over IP receiver is an supplementary solution for extending HDMI signals across greater distances via a local network setup and creating scalable IP installations by using multiple receivers when combined with 38126 and network equipment. As a point to point connection, the extender supports distances up to 100m using Cat.6 cable, or when combined with a network switch can be expanded for much larger distribution systems with up to 3 layers of network equipment. Adding the additional receivers provides additional flexibility to the setup to distribute content into various locations or displays at distance, great for use in retail, connected office installations or educational setups.For 1 to many and many to many set-ups, a managed network switch is required to be able to distribute data streams.Supporting resolutions up to Full HD 1920x1080@60Hz 4:4:4 8bit, this extender provides high quality content, perfect for eye catching digital signage, premium residential installations or AV distribution in hospitality. IR extension also provide simple control via an included IR emitter and receiver cable using an IR remote.Please Note: Either use a dedicated network, or network components which support port based VLAN.Please Note: The HDMI over IP Extender distributes in full 1080p resolution using a form of video compression which is barely perceptible. Presentations and static desktop displays/images will have a similar loss of sharpness similar to standard JPEG compression.

TypeAV receiver
Maximum resolution3840 x 2160 pixels
Cable types supportedCat5e, Cat6
Maximum transfer distance100 m
LED indicatorsY
Supported video modes480i, 1080p
Bandwidth4.95 Gbit/s
HDCPY
MaterialMetal
HDCP & EDID bypassY
Plug and PlayY
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Product colourBlack
CertificationCE, FCC, REACH
Ethernet LANY
RJ-45 input ports1
Number of HDMI outputs1
HDMI version1.2
Video out1
Remote (IR) input1
DC-in jackY
Operating voltage5 V
Input current1 A
Width100 mm
Depth65 mm
Height26 mm
Weight245 g
Package width330 mm
Package depth243 mm
Package height72 mm
Package weight550 g
AC adapter includedY
Cables includedIR sensor
ManualY
Sustainability certificatesRoHS
