LINDY Konverter HDMI auf VGA 1080p ohne Scaling

Lindy

38291

New

Connects an HDMI equipped device to a VGA display Supports resolutions up to 1920x1200 including 1080p Direct signal conversion, without scaling Compact dimensions for easy installation and use 2 year warrantyThe Lindy HDMI to VGA converter converts signals from an HDMI equipped source into an analogue VGA signal. It supports resolutions up to 1080p and 1920x1200 for PC VGA displays. This allows the connection of modern HDMI capable devices, such as PC’s, notebooks and ultrabooks, to an older VGA display or projector.The compact dimensions mean it can be easily installed in restricted spaces, allowing for tidy installation behind PCs or for use with laptop workstations. The converter provides connectivity without the expense of having to replace legacy displays and cabling when upgrading to modern PCs or laptops.

Cable length0.1 m
Connector 1HDMI Type A (Standard)
Connector 2VGA (D-Sub)
Connector 1 genderMale
Connector 2 genderFemale
Connector 1 form factorStraight
Connector 2 form factorStraight
HDMI version1.3
Maximum resolution1920 x 1080 pixels
Supported graphics resolutions1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Supported video modes1080p
Data transfer rate4.95 Gbit/s
Maximum refresh rate60 Hz
Product colourBlack
ChipsetAlgoltek AG6200A
Jacket materialPolyvinyl chloride (PVC)
Connector housing materialAcrylonitrile butadiene styrene (ABS)
Colour depth12 bit
Plug and PlayY
CertificationCE, UKCA, FCC, RoHS, REACH
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-10 - 80 °C
Operating relative humidity (H-H)5 - 95%
Cable diameter4.8 mm
Connector 1 dimensions (WxDxH)37 x 42 x 14.5 mm
Connector 2 dimensions (WxDxH)21 x 17.4 x 9.6 mm
Weight27 g
Quantity per pack1 pc(s)
Package width160 mm
Package depth20 mm
Package height160 mm
Package typePolybag
Package weight37 g
Harmonized System (HS) code84733080
