Delock LPWAN Antenna MHF® I plug -2.63 dBi 1.13 15 cm FPC internal self adhesive

Reference 12615

Condition: New

More info

This LPWAN antenna by Delock allows the usage of the 863 - 928 bands inside. It is completely compatible to GSM, LTE, ZigBee, Z-Wave, NB-IoT, ISM and LoRa.

System requirements:
• Device with one free MHF® I port

Specification:
• Connector: 1 x MHF® I plug
• Frequency range: 863 MHz - 928 MHz
• GSM, UMTS, LTE, ZigBee, Z-Wave, NB-IoT, ISM, LoRa
• Antenna gain: -2.63 dBi
• VSWR: 3.0
• Impedance: 50 Ohm
• Mounting type: self adhesive
• Operating temperature: -10 °C ~ 55 °C
• Housing material: FPC
• Colour: black
• Cable type: coaxial
• Cable type: 1.13
• Cable colour: black
• Cable diameter: ca. 1.13 mm
• Cable attenuation: 3.2 dB @ 2.4 GHz per meter
• Smallest bending radius: 4.5 mm
• Dimensions (LxW): ca. 60.0 x 25.0 mm
• Cable length incl. connector: ca. 15 cm

Package content:
• Antenna

Data sheet:
http://www.delock.de/produkt/12615/pdf.html?sprache=en
