Level One LevelOne ind. Netzteil POW-2432 24VDC 75W DIN-Schiene si

Reference POW-2432

Condition: New

More info

The POW-2432 should be able to accept a wide range of input voltages, typically from 90V AC to 264V AC, allowing it to operate in various industrial environments.

DIN-rail Mounting to fit standard DIN-rail mounting systems commonly used in industrial cabinets, allowing for easy installation and space-saving.

It's essential for the power supply to have high energy efficiency, reducing power losses and operating costs while minimizing heat generation.

Total power	75 W
AC input voltage	90 - 264 V
AC input frequency	47 - 63 Hz
Input current	1.45 A
Hold time	16 ms
Power protection features	Over voltage, Overload, Short circuit
Mean time between failures (MTBF)	486200 h
Safety	EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2)
Country of origin	China
Product colour	Blue, Silver
Operating temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Width	32 mm
Depth	102 mm
Height	125.2 mm
Weight	430 g
Package width	53 mm
Package depth	132 mm
Package height	147 mm
Package weight	700 g
Package type	Box
Master (outer) cases per pallet	20 pc(s)
Master (outer) case width	282 mm
Master (outer) case length	313 mm
Master (outer) case height	393 mm
Master (outer) case gross weight	19.6 kg
Harmonized System (HS) code	8504403090
Voltage tolerance	1%
Output voltage note	24V
